This order:

1*controller

1*romote(Registered users_)

manual(english)

Metal shell, damage, rust prevention design

Using the infrared remote control keyboard, easy to operate, compact and simple

Fingerprint verification mode, easy to use
Support the fingerprint administrator
Working voltage: dc 12 v + / - 10%
Sleep current: < 20 ma
Standby current: < 100 ma
Relay contact load capacity: 3 a
Fingerprint storage capacity: 120
Administrator fingerprint capacity: 2 pieces
User's fingerprint capacity: 118
Resolution: introducing the 450 DPI
The fingerprint entry time: < 1 s
Fingerprint search time: < 2 s
Recognize false rate: < 0.0001%
Boomed from: < 0.01%
Shell: metal
Size: 115 mm * 70 mm * 35 mm
Weight: 500 g
Product synopsis:
F007 fingerprint access control machine is a full metal structure.It USES sophisticated electronic lines and excellent production technology, high elegance, bearing extraordinary.
This product USES the international leading fingerprint identification technology, safe and reliable, and is safe to access the place with high demand choice of application of entrance guard, widely applicable to business institutions, offices, factories, residential area, etc.
This product with infrared remote control keyboard and fingerprint management for the administrator password, the operation is simple and convenient.
Can store up to a maximum of 120 fingerprints, of which two administrators fingerprints, fingerprint 118 users, each fingerprint assigned an ID number.
Second, the function introduction
dormancy
This machine is equipped with the human body sensor, when someone close to the machine into standby mode, namely people left after 30 seconds, the machine automatically enter a dormant state, enter a dormant state can save electricity, and can prolong the service life.
The administrator remote control function
With the infrared remote control, enter the administrator password enter a state of programming, can be the following:
Modify the administrator password, add fingerprints, remove fingerprints, clear fingerprints, set to open the door of time, set the tamper alarm time, remove tamper alarm.
The user fingerprint operation function
The user fingerprint ID number for 3-120, only to open the lock.
Push button operation function
External push button to open the lock.
Parameter setting function
Open time: 0 ~ 10 seconds, the factory default Settings for 5 seconds, the administrator can set by remote control.
Drive electric lock function
NC and COM terminal control cathode electric lock, adopts power unlock method, should be set to open the door for 1 to 10 seconds.
N0 and COM terminals anode electric lock control, adopts electricity unlock method, time should be set to open the door to 0 (the actual 50 ms).
Tamper alarm function
When the machine work is illegal to remove, buzzer sends out continuous alarm, automatically shut down for 1 minute.
Important information
Please do not to repair the machine, if any problem, please return to the manufacturer to repair.
Before installation on the wall if you want to punch, please carefully check wiring or line pipe, drilling or fixed clamp to use safety glasses.
