We have developed a new generation of ECG signal generator, oxygen probe detector, blood pressure simulator, such as auxiliary testing equipment, by the domestic and foreign friends of high praise. Should be part of the requirements of the development engineerEspecially for the development of ECG products engineers made a variety of abnormal wave enhanced ECG signal generator version of the model is SKX-2000SUP, this product has added more functions and more abnormal wave content on the basis of type SKX-2000G. I believe we can meet your needs.

Because professional so focused, the details determine everything, with technology to bring convenience to everyone.

Abnormal waveSignal simulatorAn instruction manual,External chargerOne,Bill of sales,Signal simulatorOne taiwan,Waveform chartOne piece,CertificateAnd so on, after receiving the goods can be checked. 7 days if there are quality problems, we replace the new machine, remove your worries.

AllFriends of the simulator,If you are the development of ECG products engineer, the store can provide technical support.

SKX-2000SUP Explain

Specific functions are as follows:

Waveform descriptionUsePM8000Monitor test

1, Waveform code1Normal ECG waveform

Data code60: heart rate60 BPM

Frequency range10-200 BPMWaveform amplitude is fixed, not affected by amplitude setting

2, Waveform code2Triangular waveform

Data code75 75BPM

Frequency range:10-400BPM

Amplitude range 0.1-4mVAdjust the amplitude adjustment.

3, Waveform code3Square wave

Data code10 1Hz

0.1-10Hz

Amplitude range 0.1-4mVAdjust the amplitude adjustment.

4, Waveform code4Sine wave

Data code10 10Hz

1-100Hz

Amplitude range 0.1-4mVAdjust the amplitude adjustment.

5, Waveform code5:QRSwave

Can changeTVolatility,QRSWaveform amplitude,QRSWaveform width,QRSWave frequency

Change the parameters by combining key

6Waveform code6Respiratory waveform

Data code30bpm

Respiratory waveform frequency adjustment range10-120second

7Waveform code7Pacing signal of positive and negative direction of pacing signal

Data code(20mSrepresentative2mS)

Frequency for60bpm

Amplitude range01.-4mVAdjust the amplitude adjustment.

Toggle positive and negative direction by combination key

Pulse width can be changed0.5-2mS

8Waveform code8Pacemaker signalQRSwave form

The pre pacing signal is positive and negative pulse waveform

The pulse width of the pacemaker can be adjusted0.5-2mS

Amplitude range01.-4mVAdjust the amplitude adjustment.

9Waveform code9Adjust waveform amplitude

Data code100 1Mv

400 4Mv

10Waveform codeA:

Data code1 75bpm normal

Data code2 140bpm Tachycardia

Data code3 35 BPM Bradycardia

Data code4 200 BPM TSupraventricular tachycardia

Data code5 80 (73) BPM Drain Bo

Data code6 14 BPM Dying rhythm

Data code7 0 bpm Arrest

11, Shape codeB:

Data code1 75bpm normal

Data code2 82bpm NSR with PAC

Data code3 82bpm Rough atrial fibrillation, heart failure

Data code4 80bpm Room early

Data code5 80bpm continuity2Three room early2Three room early

Data code6 80bpm continuity3Three room early (multiple room early)

Data code7 80bpm continuity4Three room early (multiple room early)

Data code8 80bpm Beats

Data code9 80bpm 2Continuous premature beat

Data code10 80bpm 4Continuous premature beats

Data code11 80bpm 1A premature beat, a normal waveform

Data code12 80bpm All premature ventricular fibrillation (VF)/Ventricular tachycardia

12, Waveform codeC:

Data code1 60bpm Degree block

Data code2 35bpm Degree block 35 BPM

Data code3 31bpm Degree block 31 BPM

Data code4 60bpm L bnd1 branch block

Data code5 60bpm R bnd1 branch block

13, Waveform codeD:

Data code1 (80-83)bpm ATRIAL PAC

Data code2 60bpm Pvc1 early Lv focus

Data code3 60bpm Pvc1 early Rv focus

Data code4 60bpm Nodal PNC

Data code5 60bpm Ventricular premature two

Data code6 60bpm trigeminy

Data code7 80bpm R ON T
