GSM 3G 4G S265 real-time temperature humidity monitoring alarm data logger unit for Oil pump warehouse hospital | Безопасность и

Model:S265

The S265 GSM GPRS SMS 3G 4G Temperature & Humidity Monitoring Unit can be used for remote monitoring onsite temperature and humidity,once the temperature or humidity exceeds the preset value, will send SMS to 10 user numbers to alarm. also, it supports GPRS to transfer data to remote monitoring center.

GSM/3G/4G LTE S265 Data Loggers are special for remote monitoring the onsite temperature and humidity. Not only for monitoring

Temperature & Humidity in real-time, also support high/low .SMS/Call alert to max 10 user phone numbers.

The Data Logger with large memory that can save 200000 events. Moreover,It provides 2 Relay outputs for automatically switch ON/OFF devices when Temperature & Humidity exceed high/low value and remote switch ON/OFF Device by SMS or GPRS/3G/4G.

It has been designed as a cost effective, low power, self contained data logger. It has 8 temperature & Humidity sensor inputs with embedded GSM/GPRS/3G/4G module to provide an all in one instrument for data logging, Remote data acquisition, alarm and control.

Applications

Ø Server room;

Ø Warehouse;

Ø Weather Stations remote control and data logging;

Ø Oil pump monitoring;

Ø Transformer stations;

Ø Supervision and monitoring alarm systems

Ø Transformer stations;

Ø Medicine center;

Ø Drug store ,Seafood storage, Aquarium;

Ø Supermarket, hospital, Hotel;

Ø Billboard, Ads Signs LED, etc.

Advantages

Ø  Quad band 850/900/1800/1900Mhz GSM GPRS Module inside;

Ø  3G UMTS/HSDPA/4G Modules are optional.;

Ø  32 bit MCU, reliable performance with in-built watchdog;

Ø  Support temperature & humidity monitoring remotely in real-time;

Ø  Support 8 channel temperature&humidity input interface(AM230x series T/H sensors);

Ø  Support  2 relay outputs,7A@125VAC   5A@125VAC  20A@14VDC;

Ø  High/Low Alert via SMS/Call/GPRS;

Ø  Supports 1 DNS or IP address as server;

Ø  Supports Modbus TCP, TCP/IP protocol over GPRS/3G/4G network;

Ø  Automatically resend the data while communication failure, GPRS failure will alert by SMS text;

Ø  Supports remotely restart the device, and configure it by SMS commands remotely;

Ø  Up to 10 user's phone number to receive alarm and daily report SMS/Call;

Ø  Timer report, interval period 1~65535 seconds, configurable; automatically upload status/Value to the authorized numbers;

Ø  In-built rechargeable battery, power lost/recover alarm, low maintenance, 24×7 operation;

Ø  In-built internal clock, support 11 actions on schedule at pre-set time;

Ø  Internal 16MB memory, logs more than 200000 records;

Ø  Wall mount or 35mm standard DIN rail Design, convenient installation, Dimensions 70*88*30mm;

Ø  Support Android/IOS APP, easily & friendly for use/config.

Ø  Support remote upgrade the firmware via PC.

Ø  Can be operated from anywhere, no distance limitation;

Ø  Secure - Using caller ID and password for identification, unknown callers are ignored;

Specification

Packing List

• Data Logger X 1
• Antenna X 1
• Backup Battery X 1 (Inbuilt)
• AC/DC adaptor(12V1A) X1
• User manual X 1

Note:GPRS FUNCTION IS RESERVED, IF YOU NEED, KINDLY CONTACT US DIRECTLY!
