 electric cable winder winding machine

Details

New Computer CNC Automatic Coil Winder Coil Winding Machine for 0.03-1.2mm wire

The machine not only retains all the features of previous designs, it also has a low noise level and is less sensitive to external power fluctuation. It features an integrated design: putting stepper motor driver, DC motor speed controller, brake and power supplier controlcircuits into one control box, simultaneously achieving size reduction, high performance and low cost.

Feature

Main Features

*  This series of automatic filament winder computer controller adopts the latest synchronous winding, it is with high                   precision and there will be no obstacles appear when in excessive speed winding displacement process
*  Super elevated wisdom model, it has self-inspecting functions, including the errors of the equipments, excessive speed           tracking and the calibration of the speed
*  Has vernier caliper functions and can measure the winding width and starting point easily
*  The speed of the cop motor can be changed at random when in operation, and the strand oscillator also can synchronize       with it
*  After the startup of the cop motor, the time of speed growing can be changed at random depend on the type of the                   machines
*  Obtain winding excessive speed detecting function , and it can reduce the winding speed automatically to the most                steady state
*  Can settle data: starting point, wire gage, winding displacement width, circles, speed of starting the winding, stopping            slow-speed, winding speed, slow lathe speed, winding displacement direction, winding direction, two-terminal stopping,        automatic reset, automatic start (job-hopping winding)
*  Foot-switch connection for better efficiency
*  Winding parameters and options can be set independently for each step
*  Memory capacity accommodates 999 steps of parameters with off-power memory retention

Introuduction

Advantages:
1.  Single chip microprocessor design, has further higher performance and higher functions; it also has less sensitive to             external power fluctuation or to external electromagnetic interference.

2.  Memory use FLASH ROM, capacity capable storing up to 1000 steps winding data, 9 winding parameters, and 5 options       can be independently assigned for each step. Off power memory retention without battery.

3.  Winding speed can be specified using the front panel keypad, resulting in easy programming of multi-step, multi-speed         settings.

4.  Guiding traverse shaft stepper motor with a constant-current driver offering fast wire guiding speeds.

5.  Guiding traverse shaft offering 99 steps moving speed selection.

6.  Software can be update through the personal computer.
