POE Injector 48V1A Power Supply Output Input 100-240V 50/60Hz pin4/5(+) 7/8(-) For CCTV IPC | Безопасность и защита

---



POE Injector, 48V1A POE Power Supply Output 48V1A Input 100-240V 50/60Hz, pin4/5(+),7/8(-) For CCTV IPC

    ​1.  Power Input Rated Voltage range: AC100~240V, Frequency range: 47~63Hz, Efficiency:>80% (min), AC current: 0.7A(max)    2.  Power Output Rated voltage: DC48V, Rated current: 1A, Current range: 0~1A, Ripple: 480mVp-p, Rated power: 24W, Voltage tolerance: ±3.0%, poe pin: 4&5(+), 7&8(-); Data Pin: 1236, Network distance 100m   3. Power Protection Protection Short circuit, Over load protection, Over power protection   4. Environment Working temp: 0 ~+40°C, Working humidity: 20 ~90% RH non-condensing, Storage temp & humidity: -20~+85°C, 10~95% RH, Vibration: EN 61131-2   5. Safety & EMC Standards: design refer to EN60950, Withstand voltage: I/P-O/P: 3KVAC, 5mA, 60S, Isolation resistance: I/P-O/P: 100M ohms/500VDC, EMC: EN55022 Class B   6. Important Tips this poe injector is compatible with IEEE802.3af powered device(PD), the PD must support PoE pin 4/5(+),7/8(-), Lan environment 10/100Mbps Base-T    7. Application For standard IEEE802.3af PoE devices such as wireless Access Points, Routers, IP phones, IP cameras, modems, switches, embedded computers or other network devices.   8. Package 1*EU poe injector
