WARM TIPS :

Tonwon 3 BT 3.0 Supports Android only.

Tonwon 3 BT 4.0 / WiFi Supports Android / IOS

Five Reasons to ChooseTonwon 3

1 . Read diagnostic trouble codes, nonspecific and manufacturer-specific, and display their meaning (over 3000 code definitions in the database).

2. Works on all 1996+ cars and light trucks sold in the USA (except hybrid or electric vehicles)

3. Supports all 5 OBD-II protocols(ISO15765-4 (CAN), ISO14230-4 (KWP2000), ISO9141-2, J1850 VPW, J1850 PWM)

4. No need extra Battery.Power charge directly from the OBDII car scanner interface in your vehicle make it convenient for DIYers and personal diagnosis.

5. After 30 minutes without communication will enter sleep , save battery power .

TONWON 3 FUNCTIONS:

1.Clear trouble codes and turn off the MIL ("Check Engine" light)
2.Set the maximum number of responses to obtain.
3.Remove spaces from ECU responses (to speed data transmission).
4.Store a unique identifier in EEPROM.
5.Set the CAN mask and filter with one command.
6.Easily switch between variable and fixed CAN message lengths.
7.Send CAN remote frames (RTRs).
8.This tool does not match abs and airbag system!

Some of readable parameters from the vehicle

1) Calculated Load Value
2)Coolant Temperature
3) Fuel System Status
4) Vehicle Speed
5) Short Term Fuel Trim
6) Long Term Fuel Trim
7) Intake Manifold Pressure
8) Timing Advance
9) Intake Air Temperature
10) Air Flow Rate
11) Absolute Throttle Position
12) Oxygen sensor voltages/associated short term fuel trims Fuel System status
13) Fuel Pressure
Many others...

MULTI-PROTOCOL SUPPORT:

SAE J1850 PWM (41.6 Kbaud)
SAE J1850 VPW (10.4 Kbaud)
ISO 9141-2 (5 baud init, 10.4 Kbaud)
ISO14230-4 KWP (5 baud init, 10.4 Kbaud)

ISO14230-4 KWP (fast init, 10.4 Kbaud)

ISO15765-4 CAN (11bit ID, 500 Kbaud)
ISO15765-4 CAN (29bit ID, 500 Kbaud)
ISO15765-4 CAN (11bit ID, 250 Kbaud)
ISO15765-4 CAN (29bit ID, 250 Kbaud)

NOTE:

1.Your vehicle may not support all above parameters,
How many parameters you can get is depended on the vehicle manufacturer's implementation.
2.This device does not apply to heavy duty diesel 24V vehicles (i.e. semi trucks, tractors etc).
Those vehicles use a different program and our adapters will not be compatible

Package List:

TW3 BT 3.0

TW3 BT 4.0

TW3 WIFI
