14-жильный гибкий экранированный витой кабель с сечением 0,14-0,2 мм², кодер 26awg 24awg, оловянная медь, провод для управления сигналом 485, 5 метров включено.

14-жильный гибкий экранированный витой кабель с сечением 0 14-0 2 мм² кодер 26awg 24awg оловянная медь провод для управления сигналом 485 5 метров включено.

Description

Description of Flexible Shielded Twisted Pair Cable

specification 2*2*0.14mm²（26AWG），3*2*0.14mm²（26AWG），4*2*0.14mm²（26AWG） 5*2*0.14mm²（26AWG），6*2*0.14mm²（26AWG），7*2*0.14mm²（26AWG） 8*2*0.14mm²（26AWG），10*2*0.14mm²（26AWG），13*2*0.14mm²（26AWG） 2*2*0.2mm²（24AWG), 3*2*0.2mm²（24AWG) , 4*2*0.2mm²（24AWG) 5*2*0.2mm²（24AWG), 6*2*0.2mm²（24AWG) , 7 *2*0.2mm²（24AWG) 8*2*0.2mm²（24AWG), 10*2*0.2mm²（24AWG) 2*2*0.3mm²（22AWG), 3*2*0.3mm²（22AWG) , 4*2*0.3mm²（22AWG)，5*2*0.3mm²（22AWG) Conductor Material: Tin-plated oxygen-free copper Insulation Material: special PVC(anti-wear, tensile, bending resistant) Insulation Colour:multicolor (if＜0.5mm2), black with white digital code (if≥0.5mm2) Sheath Material: special PVC (anti-wear, tensile, bending, oil resistant) Insulation Resistance: minimum 20MOhm*km 20 ° C conductor DC resistance (Ω / km): 95Ω / km Temperature Range: Mobile installation :-5℃ to 70 ℃ Fixed installation: -15℃ to 70℃ Nominal Voltage :Uo/U: 300V/300V Minimum Bending Radius: Mobile installation: 7.5* cable diameter Fixed installation: 6* cable diameter Application：it can transmit analog and digital signals in devices with control processor, or as a connection wire between instruments and control devices. It is suitable for low power consumption and uninterrupted data transmission. It is widely used in mechanical equipment, instruments, industrial equipment, computers, signal transmission systems, fixed or occasional mobile applications for industrial machine tools, suitable for any two-way communication. Specification/reference to AWG/conductor structure/approximate outer diameter(mm)±0.2

Flexible Towline Twisted Pair Shielded Signal Transmission Cable

Soft and Durable

The towline wire is soft which can withstand up to 2 million times of bends ，and be resistant to heat , frost , oil

The conductor is made of tin-plated pure oxygen-free copper .

Double shielding

better shielding through aluminum foil and tinned copper woven mesh above 80% coverage.

Twisted in pairs to enhance flexibility of wire to enhance its tensile strength.

Made in uniform thickness for low eccentricity.

Flexible Shielded wires are made of special PVC material for tensile and wear resistant.

Picture about factory’s producing

Related instructions

The flexible shielded twisted pair wire is priced at 5 meter, we will send you a whole cable of meters according to your order.such as ,if you order 10 pieces, I will send you a whole cable of 50 meters. The pictures above are all real shots, but they still not been able to display the color in 100% accuracy ,please understand.

Welcome to consult and customize, we will serve you fully.
